| ● Operating Voltage： | 7~16V |
| ● Operating Temperature： | -40℃~+85℃ |
| ● Storage Temperature： | -40℃~+95℃ |
| ● Sensor： | CMOS |
| ● Pixel Size： | 3μm / 2.9um |
| ● Aperture： | F2.0 |
| ● Resolution： | 1280×720 / 1280×800 / 1280×960 |
| ● Frame Rate： | 25fps / 30fps |
| ● Sharpness： | Central Area ≥600TVLine |
| Edge Area ≥500TVLine |
| ● Field of View (FOV) ： | HFOV=197° VFOV=152°@960P |
| HFOV=197° VFOV=120°@720P |
| HFOV=195° VFOV=151°@960P |
| HFOV =195° VFOV=129°@720P |
| ● Dynamic Range： | 120dB |
| ● Low Illuminance： | 0.1Lux |
| ● Output Signal： | LVDS POC |
| ● Dynamic White Balance： | Yes |
| ● LED Anti-Flicker： | Yes |
| ● Lens Structure： | G+P+IR |
| ● Manufacturing Process： | AA Technology Laser welding |
| Screw lock |
| ● Waterproof： | Front IP69K，Rear IP67 |
