● Operating Voltage:

9V ~ 16V

● Operating Current:

1A @12V

● Operating Temperature Range:

-40℃ ~ +85℃

● System Interface:

Hard-wired / CANFD

● Video Input:

LVDS (PoC)

● Video Output:

LVDS

● Output Pixels:

1280 x 720 / 1600 x 640

● Output Frame Rate:

≥30fps

● Image Latency:

＜100ms

● Supported Number of Connected Cameras:

A maximum of four 1M cameras can

be connected;

A maximum of four 3M cameras can

be connected

● Cold Start/Warm Start Time:

＜6s / ＜1s

CAMERA

● Signal Output:

LVDS (PoC)

● Connector:

Fakra

● Operating Voltage:

7 ~ 16V

● Operating Temperature:

-40℃ ~ +85℃

● Waterproof Rating:

Front IP69K, Rear IP67

● Resolution:

1280X720, 1280X800,

1280X960, 1920 x 1556

● Dynamic Range:

120dB, 140dB

● Low Illuminance:

0.1Lux
