• 2M DMS Camera

    ● Connector: Fakra
    ● Output Resolution: 1920 x 1200
    ● Frame Rate: 30fps
    ● Dynamic Range: 61.5dB
    ● Field of View (HFOV):

    HFOV：50 ~ 60°,VFOV：35 ~ 40°

    ● Video Signal Stabilization Time:<500ms
    ● ISP: Yes
    ● Shutter Type: Global
    ● Sensor: CMOS
    ● Wavelength: 940nm
    ● Emission Angle: 25° (Semi-angle)
    ● Operating Voltage: 9-16V (12V Rated)
    ● Operating Current:<200mA
    ● Power Supply Method: PoC
    ● Operating Temperature: -40℃~85℃
    ● Storage Temperature: -40℃~95℃
    ● Protection Class: IP5K2
    ● Installation Position: Left A-Pillar / Steering Column
